7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

Brand Name : RGH

Model Number : RT70HD005A

Place of Origin : Shenzhern,China

MOQ : 3PCS

Price : Negotiable

Payment Terms : L/C, T/T,Paypal

Supply Ability : 3.5kk

Delivery Time : 3-5weeks

Packaging Details : Standard Exportation Package

Certification : ISO9001/ISO14001

Screen Size : 7.0 inches

Resolution : 1024*600

Panel Type : IPS

Interface : LVDS

Brightness : 400 cd/m²

Viewing Angle : ALL

Touchscreen : No

Backlight Type : LED

Contact Now

7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

NO. Symbol Level Function
1 VCOM Common Voltage
2 VDD Power setting
3 VDD Power setting
4 NC NC
5 RESET RESET.PIN
6 STBYB(3.3V
)
Standby mode,usually pull high STBYB=1,normal operation
STBYB=0,timing controller,sourcedriverwill shut down,al
output high red shift
7 GND Ground
8 RXIN0- -LVDS differential data input
9 RXIN0+ +LVDS differential data input
10 GND Ground
11 RXIN1- -LVDS diffe rential datainput
12 RXIN1+ +LVDS differential data input
13 GND Ground
14 RXIN2- -LVDS diffe rential data input
15 RXIN2+ +LVDS differential data input
16 GND Ground
17 RXCLKIN- -LVDS differential CLOCK input
18 RXCLKIN+ -LVDS differential CLOCK input
19 GND Ground
20 RXIN3- -LVDS differential data input
21 RXIN3+ +LVDS differential datainput
22 GND Ground
23 NC NC
24 NC NC
25 GND Ground
26 NC NC
27 DIMO(3.3V) Backlit CABC controller signa output
28 SELB(1.8V) 6bit/8bit mode selection(Note 1)LVBIT=L",6 bits.LVBIT="H",
8 bits. (the default)
29 AVDD Power for Analog circuit
30 GND Ground
31 LEDK LED power cathode
32 LEDK LED power cathode
33 UR(1.8V) Horizontal reversalSHLR=L",leftshift SHLR="H",nghtshift:
34 U/D(1.8v) Vertical Tnversion-UPDNB="L",STVi outputs the vertical start
pulse and UD pin output "H"UPDNB="H",STV2 outputs the
vertical start pulse and up pin output
35 VGL GATE OFF Voltage
36-37 GND Ground
38 VGH Gate On Voltage
39-40 LEDA LED power anode
